Quick Details

  • Light Source: LED
  • Item Type: Light Strips
  • LED Light Source: SMD5730 Epistar
  • Type: Flex LED Strips
  • Input Voltage(V): DC24V
  • Lamp Power: 133.65W
  • Lamp Luminous Flux(lm): 11250lm
  • CRI (Ra>): 97
  • Color Temperature(CCT): 2400K
  • Working Temperature(℃): -20 - 50
  • Working Lifetime(Hour): 50000
  • Lamp Body Material: PCB+SMD5630
  • Certification: CE, EMC, LVD, RoHS, UL
  • Emitting Color: Warm White
  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: Anyhope
  • Model Number: AH-5630-24-75
  • Power: 24.75W /meter
  • LED QTY: 75LEDs/1.08Meter,375LEDs/Reel
  • View Angle: 120 degrees
  • Lumens: Max:2250lm /1.08 Meter
  • Waterproof: IP20 IP67

Packaging & Delivery

Packaging Details 5.04 meters / roll,1 roll / anti-static bag
Weight: 0.18kgs/Roll
Package: 25Rolls/Carton
Delivery Time Shipped in 3 days after payment




Product Description

TUV UL CE RoHS 2400K warm white Ra 97 DC24V led strip 5730 5 years warranty





LED Type: SMD5730          CRI>80


Working Voltage:  DC24V

Power:                 24.75W/Meter, 133.65Watt/Reel

PCB Color:            White  or Brown

LED QTY:             SMD5730, 75LEDs/Meter,375LEDs/Reel

Length:               5.04Meters/Reel

View Angle:         120 Degrees

WaterProof:         IP20 ; IP67

Color:                 Warm white, White  2700 ~ 6000K

Dimension:         5040 x 10 x 1.6mm / 198.43 x 0.39 x 0.063"



 Pitch: 13.3mm / 0.52" (Every 6 LEDs cut at 80mm / 3.15")








Working Temperature:  -20°C~5


Weight:             0.15Kgs/Reel


Package:          25Reels/Carton


Model numberColorLumen/MeterSizeLED QTY /MeterVoltagePower /MeterIP Protection
AH-5630W-24-75White 1950~22505040*10*1.6mm75DC24V24.75WIP20
AH-5630WW-24-75Warm  White1725~19505040*10*1.6mm75DC24V24.75WIP20



For White :











Lumen maintenance at 10,000hrs: 95%
Average life time: 50,000hrs


Warranty: 3 years


Certification: CE RoHS WEEE UL

Operating driver: LED Transformer with DC24V output

Compatible with Dimmer





               The flexible single color strip connect to power supply:





LED Strips should not be used in sealed or hot place, please make sure the heat emitting is good for LEDs.
