2015 new popular DC12V 6300lm 180leds per meter flexible led strip lighting

FOB Reference Price:Get Latest Price
US $6.49-6.99 / Meters | 5 Meter/Meters (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Light Source:
LED
Item Type:
Light Strips
Type:
Flex LED Strips
Input Voltage(V):
12V
Lamp Power:
14.4W/M,72W
Lamp Luminous Flux(lm):
6300lm
CRI (Ra>):
90
Working Temperature(℃):
-20 - 50
Working Lifetime(Hour):
50000
Lamp Body Material:
PCB+SMD3528
Certification:
CE, FCC, LVD, RoHS
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
Anyhope
Model Number:
AH-3528WW-12-180
Dimension::
5000*10*2.2mm /195*0.39*0.09inches
120 degrees view angle:
Red,Green,Blue,Yellow,White,Warm White,Pink,Purple
Voltage::
12V
Power::
14.4W/M, 72W/Roll
Certification::
CE RoHS
Lumens::
6300lumen
LED QTY::
180LEDs/Meter, 900LEDs/Roll
LED Type::
SMD3528, flexible led strip lighting
View Angle::
120 degrees
Warranty::
2 years
Emitting Color:
Warm White
Color Temperature(CCT):
2000-10000K
LED Light Source:
SMD3528
Supply Ability
Supply Ability:
30000 Meter/Meters per Week
Packaging & Delivery
Packaging Details
5 meters / roll
1 roll / anti-static bag
Weight: 0.21kgs/Roll
Package: 25Rolls/Carton
Port
Shenzhen China
Lead Time :
Within 3-5 working days after receiving the payment.



Product Description
2015 new popular DC12V 6300lm 180leds per meter flexible led strip lighting

Model: AH-3528WW-12-180

  • Widely used for home decoration use, hotels, clubs, shopping malls
  • Architectural decorative lighting, boutique atmosphere lighting
  • Extensively applied in Backlighting, concealed lighting, channel letter lighting
  • Emergency & security lighting, advertisement sign lighting
  • Decorative lights for holiday, event, show exhibition






Flexible LED Light Stripe - 3528SMD 180LEDs Triple



LED Type:  3528SMD, Taiwan Chip - Epistar



LED QTY: 180LEDs/Meter, 5Meters/Roll, 900LEDs/Roll, 900LEDs/16.40Ft



Pitch: 16.7mm / 0.66"




Max Lumens per LED: 3lm(Red), 3lm(Yellow), 5lm(Green), 3.5lm(Blue), 7lm(White),

6lm(Warm White)



Color Temperature: 2000K, 2200K, 2400K, 2700K, 3500K, 4500K, 5500K, 6500K, 7000K,

8000K, 10000K



14.4W/Meter, 1.2A/M(12VDC) 72W/Roll







DC12V (Every 9 LEDs cut at 50mm / 1.97")



PCB Color: Brown, White, Black (Optional)









Super Bright Warm White: 1080Lm/Meter

Super Bright Cool White: 1440Lm/Meter are available.

Note: Amber, Orange, Pink, Purple color are optional.

Max Length Connection: 5 Meters, Feed power to both ends at every 5 meters to minimize the voltage drop.



Model Number

Color

Typ.Flux
(LM/M)

LED QTY
(LEDs/M)

Voltage
(DC)

Power
(W/M)

AH-3528R-12-180

Red

540

180

12V

14.4

AH-3528Y-12-180

Yellow

540

AH-3528B-12-180

Blue

630

AH-3528G-12-180

Green

900

AH-3528W-12-180

White

1260

AH-3528WW-12-180

Warm White

1080










LED Flex Strip Type

IP

Protection

Size

Reference
Model Number

Non waterproof

IP20

24 x 2.2mm

0.94 x 0.08"

AH-3528-12-180

Epoxy / Silicon series

IP65

24 x 2.5mm

0.94 x 0.09"

AH-E3528-12-180

U-shape silicone series

IP67

27 x 5mm

1.06 x 0.19"

AH-U3528-12-180


Cable length: 35cm / 13.78"

Free end cap: 1 Piece / Meter  (Opitional)

Free mounting clip: 2 Pieces / Meter  (Opitional)

View angle: 120 degree

CRI: >80

CRI: >90 are available.

Lumen maintenance at 10,000hrs: 95%

Average life time: 50,000hrs

Storage temperature: -30°C~80°C / (-22ºF ~ + 176ºF)

Operating temperature: -20°C~50°C / (-4ºF ~ + 122ºF)

Warranty: 2 years

Certification: CE RoHS






Max Length Connection: 5 Meters, Feed power to both ends at every 5 meters to minimize the voltage drop.



Operating driver: LED Transformer with DC24V output



Compatible with Dimmer




The flexible single color strip connect to power supply:









Company Information

          Anyhope Technology Limited is a leading LED Manufacturer & Distributor of quality LED

products in Shenzhen China.

        Certified with ISO 9001: 2008 management system, 7500 square meters of workshop area and 300 employees, specialized engineers and designers, advanced auto-machines with LED package, assembly lines.







Our Services

Step (1): Quotation
We will send you the quotation within 1 day according to your detailed requirements.

Step (2): Sales Contract or Proforma Invoice
We will send you the Sales Contract or Proforma Invoice with estimated shipping cost by DHL, UPS, FedEx, bank information and terms & conditions for detailed check.

Step (3): Payment (T/T, Wire Transfer, Paypal, Western Union)

Step (4): Production Process

Step (5): Package and Shipping

Step (6): Air Way Bill Number







FAQ



Why you should use LED lighting?



Some basic advantages of LEDs:

1, Directional light emission: LEDs emit light in a specific direction, so well-designed fixtures can deliver more efficiently so the intended location.
2,Size advantage: LEDs can be very compact and low-profile.Flexible ribbon for curving around bends.
3,Breakage/vibration resistance: LEDs contain no breakable glass or filaments.
4, No IR or UV emissions: LEDs intended for lighting do not emit infrared or ultraviolet radiation, and generate no heat in the beam of light. Green environmental protection, lead-free material ,conforming to RoHS.
5,Instant On: Unlike traditional sources, like metal halide, LEDs require no "warm-up" time.Low power consumption.
6,Rapid cycling capability: LED lifetimes are not affected by frequent switching.
7,Control: LEDs are compatible with electric controls to change light levels and colors.
8, Efficacy: Currently five times more efficient than the incandescent light bulb, the cost per lumen of LEDs is decreasing 10-fold with each decade.

 You and our environment will be able to benefit in many ways with this type of lighting.







Packaging & Shipping





    5Meters/Roll, 1 Roll into anti-static bag



    50Rolls/Carton, Carton Size: 50x40x30cm / 19.69x15.75x11.81"















Accessories(Optional):





Certificate:



Factory:



Welcome to visit our website:  www.anyhopetech.com
