UL Listed 3000K 24V 3528 120 LED Per Meter CRI 90 Cuttable every 50mm Economical LED Tape Lighting

FOB Reference Price:Get Latest Price
$1.20 - $3.99 / Meters | 5 Meter/Meters (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Type:
Flex LED Strips
Input Voltage(V):
DC24V
Lamp Power:
48W
Lamp Luminous Flux(lm):
4200lm
CRI (Ra>):
90
Working Temperature(℃):
-20 - 50
Working Lifetime(Hour):
50000
Lamp Body Material:
PCB+SMD3528
Certification:
BV, C-tick, CE, EMC, Energy Star, ETL, FCC, GOST, GS, LVD, PSE, REACH, RoHS, SAA, SASO, UL, VDE
Place of Origin:
Guangdong, China
Brand Name:
Anyhope
Model Number:
AH-3528WW-24-120
Light Source:
LED
LED Qty:
120LEDs/Meter, 600LEDs/Reel
Size:
5000*8*2.2mm /196*0.32*0.09inches
Color:
Red, Green, Blue, Yellow, White, Warm White, Pink, Orange, Amber
Lifetime:
50,000 Hours
Item Type:
Light Strips
Emitting Color:
Warm White
Color Temperature(CCT):
3000K
LED Light Source:
SMD3528
Supply Ability
Supply Ability:
40000 Meter/Meters per Week
Packaging & Delivery
Packaging Details
5 meters / Reel,
Each reel in anti-static bag,
Weight: 0.195kgs/Roll
Package: 25Reels/Carton
Port
Shenzhen China
Lead Time :
Shipped in 7 days after payment
Product Description



UL Listed 3000K 24V 3528 120 LED Per Meter CRI 90 Cuttable every 50mm Economical LED Tape Lighting



DC12V,  DC24V, 48Watt / reel,  Warm White 3500K. 2400K, 2700K, 2200K



CRI: >90. 90 Lumen per watt

Ra:>80, 80 Lumen per watt











Flexible LED Light Stripe - 3528SMD 120LEDs



LED Type: 3528SMD, Taiwan Chip


LED QTY: 120LEDs/Meter, 5Meters/Roll, 600LEDs/Roll, 600LEDs/16.40Ft

Max Lumens per LED:
3lm(Red),3lm(Yellow),5lm(Green),3.5lm(Blue),7lm(White),6lm(Warm White)

Color Temperature:
2000K, 2200K, 2400K, 2700K, 3500K, 4500K, 5500K, 6500K, 7000K, 8000K, 10000K

Power: 9.6W/Meter, 0.8A/M(12VDC), 0.4A/M(24VDC), 48W/Roll


Model Number

Color

Typ.Flux
(LM/M)

LED QTY
(LEDs/M)

Voltage
(DC)

Power
(W/M)

AH-3528R-12/24-120

Red

360

120

12V
24V

9.6

AH-3528Y-12/24-120

Yellow

360

AH-3528B-12/24-120

Blue

420

AH-3528G-12/24-120

Green

600

AH-3528W-12/24-120

White

840

AH-3528WW-12/24-120

Warm White

720


Super Bright Warm White: 840Lm/Meter

Super Bright Cool White: 960Lm/Meter are available.


Color optional:

Red,Yellow,Blue,Green,White,Warm white,Amber, Orange, Pink, Purple.


Dimension:  5000*8*2.2mm /195*0.31*0.09inches




Pitch: 8.3mm / 0.33"

DC12V (Every 3 LEDs cut at 25mm / 0.98")

DC24V (Every 6 LEDs cut at 50mm / 1.97")

PCB Color: Brown, White, Black (Optional)









Cable length: 35cm / 13.78"

Free end cap: 1 Piece / Meter (Opitional)

Free mounting clip: 2 Pieces / Meter (Opitional)



LED Flex Strip Type

IP

Protection

Size

Reference
Model Number

Non waterproof

IP20

8 x 2.2mm

0.31 x 0.08"

AH-3528-12/24-120

Epoxy / Silicone series

IP65

8 x 2.5mm

0.31 x 0.09"

AH-E3528-12/24-120

Silicone tube series

IP67

10 x 4mm

0.39 x 0.16"

AH-F3528-12/24-120

U-shape silicone series

IP67

10 x 5mm

0.39 x 0.19"

AH-U3528-12/24-120

PVC Tube + Epoxy series

IP68

10 x 4mm

0.39 x 0.16"

AH-G3528-12/24-120

All silicone series

IP68

10 x 5mm

0.39 x 0.19"

AH-S3528-12/24-120




View angle: 120 degree
CRI: >80,
CRI: >90.

Lumen maintenance at 10,000hrs: 95%
Average life time: 50,000hrs

Storage temperature: -30°C~80°C / (-22ºF ~  176ºF)
Operating temperature: -20°C~50°C / (-4ºF ~  122ºF)
Warranty: 3 years
Certification: UL CE RoHS


Max Length Connection: 10 Meters, Feed power to both ends at every 5 meters to minimize the voltage drop.

Operating driver: LED Transformer with DC12V/DC24V output

Compatible with DMX Decoder, Common Anode RGB Controller, Dimmer

The flexible single color strip connect to power supply:







Packaging & Shipping









Accessories(Optional):





Welcome to visit our website: www.anyhopetech.com
